The FMAX works great with a variety of plants from tomatoes to tobacco. Its transplanter carousel turns in a clockmotion (STOP & GO), guaranteeing a consistent drop of plants from carousel to shoe.
This ensures precision of plant depth and distance within the row, as well as increased performance per hour.

Working great on both flat and raised beds, the FMAX has yield of up to 5,000 plants per hour per row.

To prevent accumulation of dirt this machine is equipped with a self-cleaning kicker in the ploughshare.

This mechanical transplanter is best for planting seedlings both in plugs and square blocks with a maximum diameter of 7 cm. One of its most striking features is its ability to transplant on plastic, paper film, and bare ground. Row width and distance within the row is adjustable depending on specific needs.
This machine can be combined with our film layer machine. Options include a carousel which increases performance by 50%.

A double carousel is available for one person to feed two rows. Watering device, granular applicator, fertilizer applicator, markers, and rollers are also available.

This transplanter has a rotary carousel best for planting vegetables in cylindrical, conical, and pyramidal plugs. Its lowest achievable row distance is 25 cm, which allows for high density plants such as lettuce, broccoli, and fennel to be easily transplanted. Its parallel linkage floats on the ground making it easy to plant evenly and precisely even in difficult ground conditions. Like many of our other transplanters this machine can work on both raised beds and flat ground.

Its transplanter carousel turns in a clock motion (STOP & GO), guaranteeing a consistent drop of plants from carousel to shoe. This ensures precision of plant depth and distance within the row, as well as increased performance per hour (up to 5,000 plants per hour per row). To prevent accumulation of dirt this machine is equipped with a self-cleaning kicker in the ploughshare. This machine is available in a self-propelled version. This guarantees easy maneuverability, reduction of dead time, and no need for a tractor.

Optionals include rubber rollers with adjustable pressure, plant spacing control, granular applicator, fertilizer applicator, water applicator, tank, front hydraulic or electronic steering arms, data memory, pack wheel pressure with hydraulic adjustment, plant depth with electric adjustment, front disk to open ground, and back forks for loading and completed pallets.

Pincer transplanter for bare root seedlings with conical and cylindrical clod max. 5 cm in diameter and cubic of max. 4 x 4 cm. Adjustable inter-row min. cm. 49, max. on demand.

SPECIAL FEATURES:

•    Fast adjustment of the transplant depth.

•    Quick adjustment of the depth of the pliers.

•    Parallelogram with front wheel.

•   Intermittent water dispenser

•    Microgranulator

•    Fertilizer spreader

•    Plow for deep transplantation (standard)

•    Hydraulic folding bar

•    PSC (Plant Spacing Control)

Differences:

SHORT CHAIN

• 10 finger planter min. cm. 23 / max cm. 77
• 15 finger planter min. cm. 16 / max cm. 52
• 20 finger planter min. cm. 13 / max cm. 77

LONG CHAIN

• 16 finger planter min. cm. 12 / max cm. 78
• 24 finger planter min. cm. 8 / max cm. 52
• 32 finger planter min. cm. 6 / max cm. 78

Mulching transplanter capable of spreading both polyethylene and biodegradable plastic film, fixing it to the ground, drilling it and transplanting it with cubic-compressed clods in a semi-automatic manner with average yields of 5,000 plants/hour per row.

3types of frame

PER PLASTIC FILM

• Width of 1400-1600 mm

• Width of 1600-1800 mm

• Width of 1700-1900 mm

In the case of widths other than those indicated, special frames can be manufactured.


• Device for cutting hydraulic film with removal of obstructive material.

• Pneumatic cylinder for the control of film pressure.

• Hydraulic lifting of the machine for inspection.

• Rear platform for cargo pallet.

• On each row there is an infeed strip that separates one clod from the other and inserts it, through the hole made by the perforator in the plastic film, into a groove traced by a ploughshare operating simultaneously under the sheet. The operation is managed by a synchronized gripper system.
  The real innovation of this machine lies in its extraordinary production capacity thanks to its general electronic management, in addition to the distance that can be set via the digital keyboard.
